The 340H Series offers high efficiency Ultra-Low NOx condensing technology allowing for the use of 3” PVC venting and has 0” clearance to combustibles. Utilizing HRS35 copper alloy for the heat exchanger tubing. Remote control included as a standard feature. Indoor models are certified up to 10,100 ft. altitude. Provides a variety of installation options: indoor, outdoor and direct vent. Complies with Ultra-Low NOx regulations and meets the energy efficiency requirements of ASHRAE 90.1b-1992.
The ATI-240H-N tankless water heater uses up to 160,000 BTUs of natural gas to deliver a max flow rate of 6.6 GPM. It utilizes condensing technology to achieve an Energy Factor of 0.95, and is ENERGY STAR® qualified. This model meets Ultra-Low NOx emission requirements, and comes with a 15-year limited warranty.
The comprehensive line of A. O. Smith tankless water heaters provide hot water on-demand.
• A hot water tap is opened
• The opened tap allows water to flow through the water heater. An internal water flow sensor detects this flow
• Upon flow detection, the flow sensor sends the activation signal to the computer board
• The computer automatically ignites the burner
• As water flows through the heat exchanger, it absorbs heat from the burner
• By the time the water exits the heater, it has reached the designated set temperature
• When the hot water tap is closed, the water heater automatically turns off
Product Specifications
| Tech Specs |
| Emissions: |
Ultra-Low NOx |
| Maximum BTUs: |
160,000 |
| Minimum BTUs: |
15,000 |
| Limited Heat Exchanger Warranty: |
15 Years |
| Limited Parts Warranty: |
5 Years |
| Water Connection Location: |
Bottom |
| Water Connection Size: |
3/4" |
| Heat Exchanger: |
Copper & Stainless |
| Secondary Heat Exchanger: |
Stainless Steel |
| Voltage: |
120 |
| Energy Factor: |
0.95 |
| ENERGY STAR®: |
Yes |
| Digital Display: |
Yes |
| Remote Control: |
Yes |
| Technology: |
Condensing |
| Dimensions & Venting |
| Type: |
Space Saving |
| Height: |
23 5/8" |
| Width: |
17 3/4" |
| Depth: |
11 1/4" |
| Product Weight: |
58lbs/26kg |
| Shipping Weight: |
62lbs |
| Vent Type: |
Power Direct Vent |
| Vent Length: |
70 feet at 3 diameter
100 feet at 4 diameter |
| Vent Material: |
PVC, CPVC, PP, ABS, SS |
