SPECIFICATIONS:
Indoor Unit:
| Depth |
8-1/2" |
| Height |
10-13/16" |
| Max. Fuse Size |
20 |
| Liquid Conn. |
1/4" |
| SEER |
16.0 |
| Suction Fitting |
3/8" |
| Wt. Lbs. |
16 |
| Amps Cooling |
10.9 |
| CFM High |
436 |
| BtuH Cooling |
12,000 |
| BtuH Heating |
14,000 |
| Width |
31-1/8" |
| Unit Type |
Indoor |
| System # |
12RL2 |
| Shipping Weight |
24.00 |
| Shipping Width |
1.00 |
| Shipping Length |
1.00 |
| Shipping Height |
1.00 |
Outdoor Unit:
| Depth |
11-1/2" |
| Height |
21-3/8" |
| Max. Fuse Size |
20 |
| Liquid Conn. |
1/4" |
| SEER |
16 |
| Suction Fitting |
3/8" |
| Wt. Lbs. |
69 |
| Amps Cooling |
10.9 |
| CFM High |
436 |
| BtuH Cooling |
12,000 |
| BtuH Heating |
14,000 |
| Width |
31-1/8" |
| Unit Type |
Outdoor |
| System # |
12RL2 |
| Shipping Weight |
88.00 |
| Shipping Width |
1.00 |
| Shipping Length |
1.00 |
| Shipping Height |
1.00 |
DESCRIPTION:
Mini-splits are economical to install and provide cooling and heating with the convenience of a remote control and best of all, turn the system off when you leave to save money on energy bills. These Mini-Splits offer additional cooling without costly changes to your home's central cooling and heating system. Mini-Splits can be used for even the most difficult to cool or heat areas. The advanced technology that goes into these units creates a far more cost effective alternative to either gas or oil-fired units for heat, or a central ducted system for air conditioning.
Cooling Performance Data :
- SEER - 16
- Cooling Capacity (BTU/h) - 3,100 to 12,500
- Cooling Operating Range from 15 to 115 Fahrenheit.
- EER - 10.0
Heating Performance Data :
- SEER - 16
- Heating Capacity (BTU/h) - 3,100 to 16,000
- Heating Operating Range from 15 to 75 Fahrenheit.
- EER - 11.5
Standard Product Features :
- Compressor - Inverter Driven Variable Speed DC Rotary
- Remote Control Included
- R-410A chlorine-free refrigerant
- High-efficiency performance
- Sleep Timer
- Dry Mode
- Powerful Operation
- Quiet Mode
- Economy Mode
- Auto Restart / Reset
- Auto Changeover
- Low Ambient
- Cold Prevention
- Manufacturers Warranty does not apply to this product
Residential Applications :
- Room additions/renovations
- Homes without duct work
- Bedrooms and family rooms
- Garage workshops
- Sun rooms
- Guest quarters
- Wine cellars
Commercial Applications :
- Hotels and other lodging
- Computer rooms/server rooms
- Restaurant kitchen and prep areas
- Offices in warehouse spaces
- Storage facilities
- Buildings where security concerns prevent the use of window units
- Internal areas without exterior wall access applications
